D6 High-Current Connector: Designed for Industrial Applications like Electric Vehicles and Energy Storage Systems
The D6 Connector is an industrial-grade solution built for high-current applications, such as electric vehicles (EVs), electric bikes (e-Bikes), energy storage systems, smart grids, and industrial automation. Its compact size and high current-carrying capability make it the perfect choice for battery modules and power transmission.
Key Advantages:
High Current, Low Loss: The connector can handle up to 160A instantaneous current (5 seconds) and 80A continuous current, with contact resistance as low as 5mΩ, ensuring efficient power transmission and minimal energy loss.
Durable and Reliable: It offers more than 3,000 mating cycles, operates within a wide temperature range of -20℃ to 85℃, has a voltage resistance of 800V DC, and is suitable for demanding environments.
Flexible and User-Friendly: The connector features a compact design, supports various wire gauges (6AWG to 8AWG), and can be shipped without wires for flexible customization by the customer.
Product Features:
High Current Capacity & Low Impedance:
2PIN power design ensures stable power delivery.
Maximum instantaneous current: 160A (5 seconds).
Continuous current: 80A.
Power terminal contact resistance: ≤ 5mΩ.
Supports 6AWG wired configurations.
Flexible Installation & Durable Design:
Easy to install and remove.
Compact size suitable for space-constrained applications.
Mating cycles exceed 3,000.
Option for wire-free shipment (customer-optimized assembly).
Exceptional Environmental Adaptability:
Voltage resistance: 800V DC.
Operating temperature range: -20℃ ~ 85℃.
Application Areas:
Autonomous Electric Vehicles
Electric Bicycles (e-Bikes)
Electric Motorcycles
Electric Scooters
Electric Vehicles (EVs) & Hybrid Electric Vehicles (HEVs)
Energy Storage Systems (ESS)
Smart Grids
Industrial Automation
Plug-and-Play Battery Modules
Why Choose the D6 Connector?
The D6 Connector delivers high reliability and performance with its remarkable current-handling capabilities, low contact resistance, and wide operating temperature range. Its compact and flexible design also makes installation and usage hassle-free, making it ideal for challenging and space-sensitive applications.
Frequently Asked Questions（FAQ）
Q1: What is the mating cycle lifespan of the D6 Connector? A1: The D6 Connector supports over 3,000 mating cycles.
Q2: What is the maximum current load capacity of the D6 Connector? A2: It can handle a maximum instantaneous current of 160A (5 seconds) and an 80A continuous current.
Q3: What applications is the D6 Connector suitable for? A3: Applications include electric vehicles, electric bicycles, energy storage systems, and more.
👉 Contact AVIN today to learn more about the D6 Connector!
Item
Specifications
Terminal Configuration
2PIN Power
Power Terminal Current
80A (Max Instant: 160A (5 sec))
Voltage Resistance
800V DC
Power Contact Impedance
≤ 5mΩ
Signal Contact Impedance
≤ 30mΩ
Mating Cycles
>3,000
Operating Temperature Range
-20℃ ~ 85℃
Supporting Wire Gauge
6AWG ~ 8AWG
